البحرية الصف U2 U3 مرساة سلسلة

الصفات الرئيسية
الاسم التجاري: Henger
مكان المنشأ: الصين
الشهادة: BV,CCS,KR,LR,NK, ABS
القدرة على العرض: 3000 طن شهريا
موعد التسليم: 1-5 أسابيع
شروط الدفع: T / T ، L / C ، D / A ، D / P ، ويسترن يونيون ، موني جرام
العبوة القياسية: عارية / البالته

ملخص المنتج

البحرية الصف U2 U3 مرساة سلسلة U2 U3 مواصفات سلسلة مرساة مسمار = قطر السلسلة الطبيعي (مم) تحميل اختبار إثبات (KN) اختبار التحميص (KN) وزنكجم / 27.5 م GRADE2 الصف 3 GRADE2 الصف 3 17.5 127 179 179 256 194 19 150 211 211 301 236 20.5 175 244 244 349 269 22 200 280 280 401 322 24 237 332 332 476 370 26 ...

سمات المنتج المخصصة

إبراز

سلسلة مرساة مسمار U3

,

سلسلة مرساة مسمار من الدرجة البحرية U2

,

سلسلة مرساة بحرية CM690

اسم المنتج:
أنكور كيان
ماتيريا:
CM490 ، CM690
اللون:
أسود أو بناءً على طلبات العميل
مقاس:
17.5 مم - 130 مم
تطبيق:
مرسى بحري
إصدار الشهادات:
CCS,BV,LR,RINA,KR,NK,GL,ABS,DNV,RS
ضمان:
سنة واحدة
مصطلح الدفع:
T / T ، ويسترن يونيون أو خطاب الاعتماد في الأفق
وصف المنتج

البحرية الصف U2 U3 مرساة سلسلة



U2 U3 مواصفات سلسلة مرساة مسمار



=

قطر السلسلة الطبيعي (مم)

تحميل اختبار إثبات (KN) اختبار التحميص (KN) وزن
كجم / 27.5 م
GRADE2 الصف 3 GRADE2 الصف 3
17.5 127 179 179 256 194
19 150 211 211 301 236
20.5 175 244 244 349 269
22 200 280 280 401 322
24 237 332 332 476 370
26 278 389 389 556 431
28 321 449 449 642 496
30 368 514 514 735 564
32 417 583 583 833 635
34 468 655 655 937 712
36 523 732 732 1050 800
38 581 812 812 1160 887
40 640 896 896 1280 1032
42 703 981 981 1400 1084
44 769 1080 1080 1540 1197
46 837 1170 1170 1680 1310
48 908 1270 1270 1810 1438
50 981 1370 1370 1960 1546
52 1060 1480 1480 2110 1661
54 1140 1590 1590 2270 1791
56 1220 1710 1710 2430 1926
58 1290 1810 1810 2600 2086
60 1380 1940 1940 2770 2249
62 1470 2060 2060 2940 2361
64 1560 2190 2190 3130 2516
66 1660 2310 2310 3300 2676
68 1750 2450 2450 3500 2885
70 1840 2580 2580 3690 3010
73 1990 2790 2790 3990 3274
76 2150 3010 3010 4300 3548
78 2260 3160 3160 4500 3737
81 2410 3380 3380 4820 4030
84 2580 3610 3610 5160 4334
87 2750 3850 3850 5500 4650
90 2920 4090 4090 5840 4976
92 3040 4260 4260 6080 5199
95 3230 4510 4510 6440 5544
97 3340 4680 4680 6690 5780
100 3530 4940 4940 7060 6143
102 3660 5120 5120 7320 6398
105 3850 5390 5390 7700 6773
107 3980 5570 5570 7960 7033
111 4250 5940 5940 8480 7569
114 4440 6230 6230 8890 7983
117 4650 6510 6510 9300 8409
120 4850 6810 6810 9720 8863
122 5000 7000 7000 9990 9143
124 5140 7200 7200 10280 9598
127 5350 7490 7490 10710 9908
130 5570 7800 7800 11140 10382





U2 U3 مرساة سلسلةتكمن



لدينا مرفق داخلي لكل عملية تفتيش:
1- التحليل الكيميائي بواسطة مطياف
2. فحص القياس
3. اختبار الخواص الميكانيكية ، نقطة الخضوع ، قوة الشد ، الاستطالة
4-الفحص غير المدمر (NDT): الأشعة السينية ، اختبار اختراق الصبغة ، فحص الجسيمات المغناطيسية

5. اختبار السقوط



البحرية الصف U2 U3 مرساة سلسلة 0



منفعتنا



1.نحن معتمدون من ISO 9000 ، مما يمكننا من تزويد عملائنا بمنتجات وخدمات أفضل وأفضل.



1. لقد كنا في هذا الخط لأكثر من 15 عامًا ، مما يمكننا من معرفة مكان الحصول على أفضل جودة وأفضل وقت للتسليم وأفضل سعر.



2. يعرف فريقنا الفني جيدًا تصنيع المنتجات وفحصها ، مما يمكننا من اختبار وفحص المنتجات بدقة على أرض عملائنا.



4. نحن من ذوي الخبرة في تصدير منتجاتنا ، والتي تمكننا من شحن المنتجات لعملائنا بأمان واقتصاديا.



البحرية الصف U2 U3 مرساة سلسلة 1



التعليمات



1. س: كيفية طلب المنتجات؟
ج: أرسل لنا استفسارًا عن التفاصيل ، كلما كان ذلك أكثر تفصيلاً كان ذلك أفضل.على سبيل المثال ، رقم الصنف ، وصف العنصر ، المادة ، الحجم ، المعالجة السطحية ، متطلبات التعبئة.إذا كان ذلك ممكنًا ، فمن الأفضل إرفاق بعض الصور أو الرسومات المرجعية أو أي روابط من موقعنا على الإنترنت لتجنب أي سوء فهم.


2. س: حول العينة:
ج: عينات الكمية الصغيرة والصغيرة مجانية.ما عليك سوى تحمل الشحن السريع.


3. س: حول وقت التسليم:
ج: يمكن أن يكون وقت التسليم وفقًا لمتطلباتك.عادة في غضون 20 يومًا بعد استلام إيداع الطلب.


4. س: حول طلب صغير:
ج: منتجات مختلفة مع موك مختلفة ، يرجى الاتصال بنا للتأكيد.


5. س: عن الدفع:
ج: T / T ، L / C ، ويسترن يونيون ...... ، يرجى الاتصال بنا للتأكيد.


6. س: كيف سيتم شحن طلبي؟
ج: عادة ما يتم شحنها عن طريق البحر أو طلب صغير أو أمر عاجل يمكن أن يكون عن طريق الجو أو عن طريق البريد السريع بعد استلام موافقتك.


7. س: ما هو ضمان الجودة الخاص بك؟
ج: لدينا أنواع مختلفة من المنتجات التي يمكن أن تلبي معايير الجودة المختلفة.سيقوم قسم مراقبة الجودة لدينا باختبار المنتجات أثناء كل عملية إنتاج.ما هو أكثر من ذلك ، قبل التعبئة والشحن ، سنختبر مرة أخرى لكل منهما.
