Pneumatic Rubber Fender with 50kpa & 80kpa Pressure and Double Layer Reinforcement for Custom Manufacturing

الصفات الرئيسية
الاسم التجاري: Henger
رقم الموديل: FFF
مكان المنشأ: الصين
الشهادة: ABS, CCS, BV, LR, DNV
الحد الأدنى لكمية الطلب: 1
سعر: $1128
القدرة على العرض: 500 قطعة/شهر
موعد التسليم: 5-8 يوم عمل
شروط الدفع: خطاب الاعتماد، D/A، D/P، T/T، ويسترن يونيون
العبوة القياسية: البليت

ملخص المنتج

حاجز مطاطي هوائي مع نسيج بطانة داخلية لتعزيز الطبقة المزدوجة. أحجام مخصصة، هيكل مطاطي متين، ضغط 50-80 كيلو باسكال، مدة صلاحية 24 شهرًا. معتمدة من قبل ISO9001، CCS، DNV، LR. امتصاص فائق للطاقة لعمليات الإرساء من سفينة إلى سفينة.

سمات المنتج المخصصة

إبراز

Pneumatic Rubber Fender with 50kpa pressure

,

Pneumatic Rubber Fender with double layer reinforcement

,

Custom Pneumatic Rubber Fender with 80kpa

مادة:
مطاط صناعي عالي القوة (النيوبرين/NBR)
يكتب:
نفخ هوائي درابزين
نطاق القطر:
0.5 م إلى 5.0 م
نطاق الطول:
1.0 م إلى 10.0 م
ضغط العمل:
0.05 ميجا باسكال إلى 0.15 ميجا باسكال
درجة حرارة التشغيل:
-30 درجة مئوية إلى +70 درجة مئوية
وصف المنتج
Pneumatic Rubber Fender with Inner Lining Fabric for Double Layer Reinforcement
Product Overview

The Sea Pneumatic Rubber Fender is an advanced marine cushioning device designed to provide superior protection for vessels during docking, mooring, and ship-to-ship transfers. Renowned for its exceptional performance and durability, this fender is widely used in various maritime applications to absorb kinetic energy and minimize impact forces, thereby preventing damage to both ships and port infrastructure.

Manufactured using high-quality rubber and reinforced with multiple layers of synthetic fiber, the Sea Pneumatic Rubber Fender ensures long-lasting resilience even in the harshest sea conditions. The pneumatic design incorporates an air-filled inner tube, allowing the fender to maintain optimal buoyancy and elasticity while floating effortlessly on the water's surface.

Key Features
  • Durable shipping pneumatic rubber fender designed for long-lasting performance
  • Heavy duty pneumatic fender capable of withstanding high impact and harsh marine environments
  • Harbor inflatable rubber fender suitable for various types of vessels and docking operations
  • Excellent energy absorption to protect ships and docks during berthing
  • Made from high-quality rubber materials ensuring resistance to abrasion and weathering
  • Easy to install and maintain with inflatable design for adjustable pressure
  • Provides superior cushioning effect to minimize damage during ship-to-ship and ship-to-dock contact
  • Available in multiple sizes to fit different vessel and harbor requirements
  • Compliant with international maritime safety standards
Technical Specifications
Product Name Inflatable Rubber Marine Fender / Marine Pneumatic Rubber Fender / Sea Pneumatic Rubber Fender
Material High-strength synthetic rubber (Neoprene/NBR)
Type Inflatable Pneumatic Fender
Diameter Range 0.5 m to 5.0 m
Length Range 1.0 m to 10.0 m
Working Pressure 0.05 MPa to 0.15 MPa
Test Pressure 0.3 MPa to 0.6 MPa
Impact Energy Absorption Up to 10000 kJ
Operating Temperature -30°C to +70°C
Color Black (custom colors available)
Applications Ship-to-Ship, Ship-to-Dock, Ship-to-Barge operations
Features High energy absorption, Low reaction force, Durable and corrosion resistant
Applications

The Henger Inflatable Rubber Marine Fender is an essential product designed for a wide range of maritime applications, providing superior protection for vessels and port infrastructure. With a customizable model number and a minimum diameter of 500mm, this product can be tailored to meet diverse customer requirements.

Certified by international standards including ISO9001:2000, CCS, DNV, and LR, the Henger Floating Pneumatic Rubber Fender ensures reliability and safety in all marine environments. Primarily used in ship-to-ship (STS) operations, vessel mooring, and ship-to-dock scenarios, the Vessel Pneumatic Rubber Fender effectively absorbs kinetic energy during berthing, minimizing damage to both the vessel and the berth.

Support & Services

Our Pneumatic Rubber Fenders are designed to provide superior performance and durability in marine applications. For technical support and services, we offer comprehensive assistance including installation guidance, maintenance tips, and troubleshooting advice to ensure optimal functionality of the fenders.

We provide detailed product manuals and technical documentation to help users understand the specifications and operational procedures. Our support team is equipped to address any technical inquiries and offer solutions for common issues related to air pressure regulation, material wear, and impact absorption.

Packing & Shipping

Product Packaging: The Pneumatic Rubber Fender is carefully packaged to ensure maximum protection during transportation. Each fender is wrapped with a protective film or plastic sheet to prevent surface damage and contamination. It is then placed in a sturdy wooden crate or reinforced cardboard box, depending on the size and quantity of the order.

Shipping: We offer flexible shipping options for the Pneumatic Rubber Fender, including sea freight, air freight, and land transportation. The fenders are securely loaded and fastened to prevent movement during transit. Shipping schedules and routes are optimized to provide timely delivery while minimizing costs.

Frequently Asked Questions
What is the minimum diameter available for the Henger Pneumatic Rubber Fender?
The minimum diameter for the Henger Pneumatic Rubber Fender is 500mm, and the size can be customized according to customer needs.
What certifications does the Henger Pneumatic Rubber Fender have?
The fender is certified by the International Quality Management System ISO9001:2000, Chinese Classification Society (CCS), Det Norske Veritas (DNV), and British Lowe (LR).
What is the price range for the Henger Pneumatic Rubber Fender?
The price for the Henger Pneumatic Rubber Fender ranges from 5000 to 10000 USD, depending on the specifications and customization.
What are the payment terms accepted for purchasing the Henger Pneumatic Rubber Fender?
We accept multiple payment terms including L/C, D/A, D/P, T/T, Western Union, and MoneyGram.
How long does it take to deliver the Henger Pneumatic Rubber Fender after placing an order?
The delivery time for the Henger Pneumatic Rubber Fender is typically between 7 to 15 working days, with factory direct supply.
